8mm Metric Shouldered Eye Nuts To DIN 582

$2.00
SKU
359208

Beaver lifting eyebolts and eyenuts come in a range of threads, including BSW, UNC, and Metric, and are predominately used for lifting applications. This eyebolt is rated to DIN 582. It is recommended that all eyebolts used for lifting be of forged steel, and be equipped with shoulders, or collars. The plain or shouderless eyebolt is fine for vertical loading but as soon as it is loaded at an angle it is subjected to bending and the load it can safely carry is reduced.

Beaver 359208 8mm Metric Shouldered Eye Nuts To DIN 582

MH5592

Specifications:

  • Thread Size: 8mm
  • WLL: 0.14t
  • Transverse Load Tonne: 0.03
  • Finish: Zinc Dichromate
  • Weight: 0.05kg
  • Dimensions:
    • W - 36mm
    • H - 36mm
    • D1 - 20mm
    • D2 - 8mm
    • D3 - 8mm
    • D4 - 20mm
    • E - 8.5mm
More Information
Model Number359208
BrandBeaver
