4700kg (4.7t) 19 x 22mm Hot Dipped Galvanised Screw Pin Dee Shackle
$21.90
SKU
241319P
These hot dipped galvanised screw pin dee shackles are manufactured by Beaver. Screw pin shackles are recommend for use in long-term or permanent applications, or where the load may slide on the pin, causing a rotation of the pin. Please note that all dimensions are nominal. Actual dimensions fall within the tolerances of AS 2741.
Beaver 241319P 4700kg (4.7t) 19 x 22mm Hot Dipped Galvanised Screw Pin Dee Shackle
MH2413P
Specifications:
- Size: 19mm x 22mm
- WLL: 4.7t
- Shackle Colour: Hot Dipped Galvanised
- Dimensions:
- Diameter - 19mm
- Pin Diameter (D) - 22mm
- Inside Width (W) - 32mm
- Inside Length (L) - 60mm
- Diamter Boss (e) - 48mm
| Model Number | 241319P |
|---|---|
| Brand | Beaver |
