Mitutoyo Dial Indicator
$389.00
SKU
3058A-19
Make the Mitutoyo 3058A-19 Series Large Face Dial Indicator with Lug part of your setup. The large face is easy to see when it's time to take a reading, and it's clearly marked with graduations in 0.01 mm increments for precise tracking. Each large dial indicator comes with limit pins and an outer frame clamp for a streamlined setup with your equipment.
MTI Qualos 3058A-19 Mitutoyo Dial Indicator
Features:
- Standard 0.01mm graduation dial gauges having an outer frame with an outside diameter of 43.9mm
- Bezel/crystal is one piece, sealed with O-ring to completely keep out contaminants
- Limit hands for positive tolerance setting and clear crisp graduations for easy reading
- Spindle and stem made of stainless steel and hardened for extreme durability and toughness
- Tungsten carbide contact point
- Bezel/crystal can be removed easily from the front side for maintenance and service
Specifications:
- Range: 0-50mm
- Graduation: 0.01mm
- Range/Rev: 1mm
- Dial Reading: 0-100
- Type: with flat
- Accuracy: +/- 0.035mm
- Measuring force: 3.0N or less
- Stem/Shank: 8mm
- Contact Point: M2.5 x 0.45 Thread
- Shockproof Type: Yes
- Jeweled Bearing Type: Yes
- With Coaxial Revolution Counter Type: Yes
- With Damper at Lowest Rest Point Type: No
- Type: ISO/JIS
| Model Number | 3058A-19 |
|---|---|
| Brand | MTI Qualos |
