Plastic Pipe Tracer 20M

$1,529.00

SKU

YIRPPT-20-33

Utilities and utility contractors have, for years, used Sondes to follow non-metallic main service pipes underground and to record their route or locate the position of blockages within those pipes. However, with pipes less than 2 or 50mm in diameter, standard sized Sondes are simply too large to fit into the pipe or to negotiate the tighter bends often found on these pipes runs.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

CScope Plastic Pipe Tracer 20m YIRPPT20-33

The unique C.Scope Plastic Pipe Tracers are designed specifically to allow SMALL diameter, non-metallic pipes to be traced.

C.Scope Plastic Pipe Tracers are the smallest diameter product on the market and can be successfully inserted into pipes when nothing else fits. Their unique construction gives unparalleled reliability and yet allows both line tracing AND the all-important end tracing using the remarkable Sonde technology housed at the very tip of the Tracers.

Features:

Extremely small diameter can be used in pipes down to 10mm.
Highly robust, resistant to kinking.
Available in 20metre and 50metre lengths.
Full length or tip only detection capability.
Water and gas proof.
Uniform diameter to allow easy use with any proprietary insertion gland.

Specifications:

Frequency: Operates at 32,768Hz
Detection Depth Range:
- Line Detection: 3m (dependent upon Locator and Signal Generator type and site conditions)
- Tip Detection: 4m (dependent upon Locator and Signal Generator type and site conditions)
Compatibility: Any Signal Generator or Transmitter with 33kHz or 33/131kHz combined output
Rod Length: 20m
Rod and Sonde Diameter: 6mm
Rod Minimum Bend Radius: 50mm
Construction:
- Reel: Robust plastic housing
- Rod: Flexible, chemical resistant plastic
Reel dimensions (20m): 150 x 120 x 250mm
Reel weight (20m): 1248 g
Operational Temperature Range: -20ºC to 50ºC
Storage Temperature Range: -20ºC to 50ºC
IP rating for actual Tracer Rod & Tip: IP68
IP rating for Plastic Pipe Tracer Casing: IP54

More Information

More Information
Model Number	YIRPPT-20-33
Brand	Topcon
