RL-H5A Rechargeable Self-Leveling Rotary Grade Laser Level + LS100D

Topcon Red Beam Rotary Laser with Rechargeable Battery RL-H5A with LS-100D Receiver 1021200-10

Kit Includes;

• Topcon RL-H5A Rotating Laser Level
• Topcon LS-100D Receiver (Millimetre)
• Topcon Receiver Clamp
• Ni-MH Rechargeable Battery
• Carry Case
• Operator Manual
• Australian Calibration Certificate

---

Topcon Red Beam Versatile Rotary Laser RL-H5A with Rechargeable Battery

The RL-H5A can be used for horizontal and sloping laser applications. Slopes up to ±5% can be used in either the X or Y axis.

Grading, excavating and general construction projects are all perfect applications for the RL-H5A. With the added “Slope Matching” feature, check grade on all your flat and slope work. The 600-rpm rotation speed makes the RL-H5A a great match with any machine mounted laser sensor.

The RL-H5A excels in long range operation. Need to shoot elevations up to 400m from your laser? No problem! This instrument has the power and range to cover a 800m (diameter) jobsite. With efficient power usage, the RL-H5A has a long battery life. The unit also gives you the option of two forms of power, 60 hours with the rechargeable (Ni-MH) battery pack.

The RL-H5A is “jobsite tough” and with its IP66 rating, the unit can withstand dust, a sudden shower and even torrential rainfall. Topcon stands behind this reliable and accurate laser with a 5-year guarantee which is the best factory warranty in the industry.

Features:

• Long-range operation (800 m)
• Smart long-range receiver
• Simple, intuitive manual slope capability
• ±10 Arc second horizontal accuracy
• Extra-long battery life (100 hours)
• Tough IP66 weatherproof rating

Specifications:

• Accuracy: ±10 Arc
• Self-Levelling Range: Horizontal ±5°
• Working Area: 800 m
• Rotation Speed: 600 rpm
• Operating Temperature: -20°C to 50°C
• Dimensions (H x W x L): 205 x 211 x 172 mm
• Dust / Humidity: IP66
• Operation Time: Ni-MH: 60 hours

Topcon LS-100D - Compact Digital Laser Sensor

Versatile and designed for maximum user convenience, the LS-100D features a digital readout to confidently deliver elevation and vertical alignment control on demand.

It features an extra-wide beam capture sensor that also rejects annoying interference from strobe light exposures. The large and bright LCD displays (front and rear) feature 9-channels of grade information and digitally show the distance to on-grade. By pressing the Hold Button, the display is locked so the user can conveniently read the results. For added versatility, three coloured LED's and a strong magnet mount are imbedded for vertical operation, ideal for steel erection or operator grade checking while excavating.

To assist in monitoring the Topcon rotating laser, alert icons appear on the LCD if the instrument is disturbed (HI alert) or when the laser battery is low.

Specifications

• Working Range (Diameter): 800m (with RL-H4C, RL-SV2S and RL-200 Series)
• Vertical Detecting Range: 90mm (3.5 in.); (-30mm to +60mm) (-1.1 in to +2.3 in.)
• LCD Digital Readout Range: 70mm (2.7 in.); (-20mm to +50mm) (-0.7 in. to +1.9 in.)
• Horizontal Detecting Range: ±45°
• Strobe Light Suppression: Yes
• Unit: mm / cm / inch / fractional inch
• On-grade Resolution: ±0.5 mm (±0.02 in.), ±1.0 mm (±0.05 in.), ±2.0 mm (±0.1 in.), ±5.0 mm (±0.20 in.), ±10.0 mm (±0.50 in.).
• LCD Grade Indicators: 9 channels
• LED Grade Indicators: Orange, Green, Red (On/Off selectable)
• Display: LCD on each side
• Buzzer: Loud/Low/Off selectable
• Bubble tube: Yes
• Warning Icons: HI Alert, Low Battery (for the RL-H4C, RL-SV2S, & RL-200 Series)
• Battery: one AA/LR6 dry-cell battery
• Operating Time: up to 45 hours with alkaline batteries
• Battery level indicator: LCD Icon
• Auto shut-off: approx. 30 minutes
• Dust/Water Rating: IP67 (IEC 60529)
• Operating Temperature: -20° to 50°
• Dimension (I x W x H): 134 x 69 x 25 mm
• Weight: 190g (including 1 x AA/LR6 Battery)
• Magnet Mount: 2 round magnets on top
• Sensor Holder 100: Screw Mount (standard component)
