13500kg (13.5t) 35 x 38mm Yellow Pin GS Safety Pin Anchor Bow Shackle
$139.00
SKU
244335
These yellow pin Grade S safety pin shackles are manufactured by Beaver, and comply to AS 2741. Safety pin shackles are used for long-term or permanent applications, or where the load may slide on the pin, cuasing rotation of the pin. The Grade S shackles are recommended where high strength is required such as lifting, towing, and 4WD applications.
Beaver 244335 13500kg (13.5t) 35 x 38mm Yellow Pin GS Safety Pin Anchor Bow Shackle
Specifications:
- Size: 35mm x 38mm
- WLL: 13.5t
- Type: Grade S
- Shape: Bow
- Closing Method: Safety Pin
- Weight: 6.94kg
- Dimensions:
- Diameter: 32mm
- Pin Diameter (D): 35mm
- Inside Width (W): 52mm
- Inside Length (L): 119mm
- Width of Bow (B): 83mm
- Diameter Boss (F): 76mm
| Model Number | 244335 |
|---|---|
| Brand | Beaver |
